UCS Mast
2027 UCS MAST NEW
Manufacturer name: UCS Mast
Price on request
Based on Starboard's product introduction. Please contact us about availability in Korea, arrival, price and the configurations you can order.
Board-foil connection
Choose between the lightweight, slim and rigid Dynacore Carbon mast, the ultra-stiff Solid Core C400/C600 Carbon (Deep Tuttle) or the robust and accessible Aluminium mast connection to your foil.
WHAT’S NEW?
- NEW Constructions
- NEW Sizes
- NEW UCS Connection
- NEW Graphics
Sizes · Prices
| Size · specification | Item ID | Price |
|---|---|---|
| 72cm · Aluminium · Top Plate | — | On request |
| 75cm · Aluminium · Deep Tuttle | — | On request |
| 77cm · Dynacore Carbon · Top Plate | — | On request |
| 82cm · Aluminium · Top Plate | — | On request |
| 82cm · Dynacore Carbon · Top Plate | — | On request |
| 88cm · Dynacore Carbon · Top Plate | — | On request |
| 92cm · Aluminium · Top Plate | — | On request |
| 95cm · Aluminium · Deep Tuttle | — | On request |
| 95cm · C400 Carbon · Deep Tuttle | — | On request |
| 95cm · C600 Carbon · Deep Tuttle | — | On request |
Description
WHAT CAN YOU EXPECT?
- Choose between the lightweight, slim and rigid Dynacore carbon mast, the ultra-stiff Solid Core C400/C600 carbon or the robust and accessible Alu mast connection to your foil.
- Introducing all-new Dynacore carbon construction for minimum weight and maximum rigidity.
Key Features
NEW UCS CONNECTION
The Universal Connection System (UCS) delivers up to 3x the torsional stiffness of previous drop-through style connection systems. Double rows of side-by-side mast-fuse screws distribute loads both laterally and longitudinally, creating maximum stability, while the supported mast-fuse saddle preserves the fuselages full structural integrity by eliminating the material cut-outs required by traditional drop-through systems. A unique sleeve-saddle fuse-wing connection provides further stability and support for the stiffest overall connection between mast, fuselage and front/tail wings.
NEW TAPERED SLIM DESIGN
Featuring a slim 14 mm thickness and tapered short chord length, reducing drag and minimising resistance through the water. This highly efficient profile delivers an optimal balance of stiffness and low drag for a faster, smoother and more responsive ride.
NEW WASTE2WEAR MAST COVER
Made from durable Waste2Wear recycled fabric, the protective mast cover keeps your foil protected during storage and transport. A strategically placed hanging hook makes garage storage and transportation simple and convenient. *Included with Dynacore Carbon mast.
Available Sizes
NEW 72 CM
Ideal for: Entry-level to progressing foilers seeking a direct, stable and confidence-inspiring ride close to the water, with easier take-offs and predictable handling in chop.
Available in:
- Aluminium – Top Plate
NEW 75 CM
Ideal for: Entry-level to progressing windsurf (Deep Tuttle) foilers seeking a direct, stable and confidence-inspiring ride close to the water, with easier take-offs and predictable handling in chop.
Available in:
- Aluminium – Deep Tuttle
NEW 77 CM
Ideal for: Downwind, pump and wave foilers seeking the most direct, stable and controlled ride, with easy take-offs and a low ride height close to the water.
Available in:
- Dynacore Carbon – Top Plate
NEW 82 CM
Ideal for: All-round foiling, freeride and freestyle riders seeking a balance of direct feel, control and added ride height.
Available in:
- Dynacore Carbon – Top Plate (Weight: 1.9kg)
- Aluminium – Top Plate
NEW 88 CM
Ideal for: Advanced foilers seeking greater clearance, leverage and control for high-speed riding, hard carving and larger swell.
Available in:
- Dynacore Carbon – Top Plate
NEW 92 CM
Ideal for: Advanced foilers seeking greater clearance, leverage and control for high-speed riding, hard carving and larger swell.
Available in:
- Aluminium – Top Plate
NEW 95 CM
Advanced windsurf (Deep Tuttle) foilers seeking greater clearance, leverage and control for high-speed riding, hard carving and larger swell.
Available in:
- C400 Carbon – Deep Tuttle
- C600 Carbon – Deep Tuttle
- Aluminium – Deep Tuttle
Constructions
DYNACORE CARBON NEW
STIFF, FAST & LIGHT
- A thin, anti-cavitation front profile reduces drag for high speed and enhanced agility. Layers of uni-directional (UD) carbon run continuously from the base to the fuselage, maximising longitudinal stiffness, while 30° UD carbon layers minimise torsion and improve lateral stability. Woven carbon twill reinforces the leading and trailing edges for increased impact resistance.
- At just 1.9 kg, the go-to 82 cm size Dynacore Carbon mast delivers an exceptional stiffness-to-weight ratio, making it ideal for fast, precise and dynamic freeride-freestyle riding.
- *Includes Waste2Wear hanging mast cover.
SOLID CORE CARBON
STIFF & FAST
- A Deep Tuttle windsurf foil mast featuring a thin, anti-cavitation front profile that reduces drag for high-speed performance and enhanced gybing.
- Available in C400 and C600 carbon constructions for increased stiffness and performance.
- C400: High modulus HM carbon fibre (tensile modulus in the range of 400 GPa).
- C600: Ultra-high modulus UHM carbon fibre (tensile modulus from 600 GPa and higher).
- *Includes mast cover.
ALUMINIUM NEW
ROBUST & ACCESSIBLE
- Thick sidewalls and internal ribs deliver exceptional stiffness, strength and torsional resistance, creating a remarkably stable and controlled ride at an affordable price.
- The perfect stepping stone into the world of UCS – one of the stiffest foil connection systems available.
USE CHART
| MASTS | Wing – Freeride | Wing – Race | Parawing | Windsurf – Freeride | Windsurf – Race | Downwind | Pump | Surf |
|---|---|---|---|---|---|---|---|---|
| 72cm (Alu – Top Plate) | X | X | X | X | X | |||
| 75cm (Alu – Deep Tuttle) | X | |||||||
| 77cm (Carbon – Top Plate) | X | X | X | X | X | |||
| 82cm (Carbon – Top Plate) | X | X | X | X | X | |||
| 82cm (Alu – Top Plate) | X | X | X | X | X | |||
| 88cm (Carbon – Top Plate) | X | X | X | X | X | |||
| 92cm (Alu – Top Plate) | X | X | X | X | X | |||
| 95cm (Carbon C400 – Deep Tuttle) | X | X | ||||||
| 95cm (Carbon C600 – Deep Tuttle) | X | X | ||||||
| 95cm (Alu – Deep Tuttle) | X | |||||||
| X-15 Class | ||||||||
| 100cm X-15 (Carbon C600 – Deep Tuttle) | X | |||||||
| 100cm (Carbon C600 – Deep Tuttle) | X |
